15. STEERING / SUSPENSION
15-4
Loosen the socket bolts for the front brake master
cylinder, and remove front brake master cylinder.
Caution
Do not let foreign materials enter into the cylinder.
Remove 2 screws, and then remove throttle
hosing holder and throttle hosing.
Loosen the socket bolts for the front brake master
cylinder, and remove front brake master cylinder.
Caution
Do not let foreign materials enter into the cylinder.
Loosen 2 screws, and then remove handle left
switch and choke hosing.
2 Screws
2 screws
Handle protect cover
brocket bolts
Master cylinder bolts
Handle protect cover
brocket bolts
Master cylinder bolts
