16. REAR BRAKE & REAR WHEEL & REAR CUSHION
16-6
Bend out the rear axle nut fixed plate.
Remove rear wheel axle nuts.
Special tool:
Rear axle nut wrench (55mm)
Remove rear brake disk bracket and disk.
Remove rear wheel axle and driven sprocket
holder.
To this chapter contents
Brake disk bracket
Driven sprocket holder
Fixed plate
