17. ELECTRICAL SYSTEM
17-17
Headlight Switch
Pin
Position
BAT3 LO HI PL
●
Wire color
White
/ Black
White Blue Brown
Winker switch
Pin
Position
R WR L
N PUSH OFF
Wire color Pink Black
Brown /
White
Horn switch
Pin
Position
BAT3 HO
FREE
Wire Color White/ Black Light green
Hazard switch
Pin
Position
HD E
●
Wire Color Green / Red Green
Winker switch
To this chapter contents
Headlight switch
Horn switch
Hazard switch
