1. GENERAL INFORMATION
1-1
Symbols and Marks............................. 1-1
General Safety ..................................... 1-2
Service Precautions............................ 1-3
Specifications...................................... 1-9
Specifications...................................... 1-10
Specifications....................................... 1-11
Torque Values ...................................... 1-12
Troubles Diagnosis.............................. 1-14
Parts to Be Greased............................. 1-19
Symbols and Marks
Symbols and marks are used in this manual to indicate what and where the special service are needed, in
case supplemental information is procedures needed for these symbols and marks, explanations will be
added to the text instead of using the symbols or marks.
Warning
Means that serious injury or even death may result if procedures are not
followed.
Caution
Means that equipment damages may result if procedures are not followed.
Engine oil
Limits to use SAE 10W-30 API SG class oil. Warranty will not cover the
damage that caused by not apply with the limited engine oil.
(Recommended oil: KING MATE G-3 oil)
Grease King Mate G-3 is recommended.
Gear oil
King Mate gear oil serials are recommended. (Bramax HYPOID GEAR OIL
# 140)
Locking sealant
Apply sealant; medium strength sealant should be used unless otherwise
specified.
Oil seal
Apply with lubricant.。
Renew
Replace with a new part before installation.
Brake fluid
Use recommended brake fluid DOT3 or WELLRUN brake fluid.
Special tools
Special tools
Correct
Meaning correct installation.
Wrong
Meaning wrong installation.
Indication Indication of components.
Directions
Indicates position and operation directions
Components assembly directions each other.
Indicates where the bolt installation direction, --- means that bolt cross
through the component (invisibility).
