Command Line Interface
5-15
show ip http server
Use the show ip http server command to display
telnet.
show ip http server
S
YNTAX
D
ESCRIPTION
:
The show ip http server comman
d has no arguments or keywords.
D
EFAULT
V
ALUE
:
The show ip http server command has no default setting.
C
OMMAND
M
ODES
:
Privileged EXEC
R
EFERENCE
:
None
M
ENU
:
Basic Switch Configuration Menu -> User Interface Config
uration Menu
E
XAMPLE
:
Switch#
show ip http server
Web Server
---------------
enabled
Switch#
182
184
