ES3000 User Guide
A-2
A.2 RJ-45 Plug and RJ-45 Connector
In a Fast Ethernet network, it is important all 100BASE-T certified Category 5 cabling use RJ-45 plugs.
The RJ-45 plug accepts 4-pair UTP or shielded twisted-pair (STP) 100-ohm cable and connects into
the RJ-45 connector. The RJ-45 connector is used to connect stations, hubs, and switches through
UTP cable; it supports 10 Mbps, 100 Mbps, or 1000 Mbps data transmission.
Operating Humidity
10% to 40 % (without condensation)
MTBF
ES-3000-PWR-10-WW - 140,000 hours @ 25 C
ES-3000-10-WW - 355,000 hours @ 25 C
FIBER-3000-1S-WW - 1,125,000 hours @ 25 C
Pin
Normal Assignment on
Ports 1 To 8
Uplink Assignment on
Port 8
1 Input Receive Data + Output Transmit Data +
2 Input Receive Data - Output Transmit Data -
3 Output Transmit Data + Input Receive Data +
6 Output Transmit Data - Input Receive Data -
4, 5, 7, 8 Internal termination, not used for
data transmission
Pin Channel Description
12 A Rx/Tx Data +Rx/Tx Data
36 B Rx/Tx Data +Rx/Tx Data
45 C Rx/Tx Data +Rx/Tx Data
78 D Rx/Tx Data +Rx/Tx Data
