Command Line Interface
5-75
EXAMPLE:
! create a 802.1Q vlan untag port 1-5, 10, 15-19
Switch(config)# interface vlan3
Switch(config-if)# name VLAN-3
Switch(config-if)# member 1-5,10,15-19
Switch(config-if)#
! modify participation (remove 10, 15-19)
Switch(config)# interface vlan3
Switch(config-if)# member 1-5
Switch(config-if)#
forbidden
Use the forbidden command to create a new VLAN or modify an existing one in the system.
interface <vlanID>
forbidden <port list>
S
YNTAX DESCRIPTION: <vlanID> VLAN ID
<port list> A list of port instances
C
OMMAND MODES: Interface configuration
R
EFERENCE: None
M
ENU: Advanced Switch Configuration Menu->VLAN Management->
Create VLAN Set VLAN ID VLAN name Select Port Member
E
XAMPLE:
! Set port 6-7 to Forbidden on vlan 3
Switch(config)# interface vlan 3
Switch(config-if)# forbidden 6-7
Switch(config-if)#
