ES3000 Use
r Guide
5-80
show vlan port
Use the show vlan port command to display
VLAN information.
show vl
an port
S
YNTAX
D
ESCRIPTION
:
D
EFAULT
V
ALUE
:
The show vlan
port command has
no default setting.
C
OMMAND
M
ODES
:
Privileged EXEC
R
EFERENCE
:
M
ENU
:
E
XAMPLE
:
Switch# show vlan port
Port PVID Acceptable Frame
Type GVRP
---- ---- ----------------
----- --------
1 1 Admit All
Enabled
2 1 Admit All
Enabled
3 1 Admit All
Enabled
4 1 Admit All
Enabled
5 2 Admit All
Enabled
6 1 Admit All
Enabled
7 1 Admit All
Enabled
8 1 Admit All
Enabled
9 1 Admit All
Enabled
Switch#
247
249
