Technics SU-GX70 User Manual

92
Operations
Using AirPlay
(Continued)
You can play back music stored on iOS
device, etc. using AirPlay.
■
Preparation
• Complete the network settings. (⇒ 28)
• Connect the iOS device or PC to the same network
as this unit.
1
(iOS device)
Start the “Music” (or iPod) app.
(PC)
Start “iTunes”.
2 Select “Technics-SU-GX70-
****
”
*
1, 2
from
the AirPlay icon (e.g.
).
• If the device name is set on the Google Home
app or Apple Home app, the set name is
displayed.
3 Start play.
• Check the volume settings before starting the
playback.
• When AirPlay is used for the first time, the volume
may be output at the maximum setting.
• The playback will start with a slight delay.
*
1: “
****
” stands for a number that is unique to
each set.
*
2: The device name can be changed from “This
unit’s name on the network”. (⇒ 37)

Technics SU-GX70 Specifications

General

Type	Integrated Amplifier
Input Impedance	47 kΩ
Speaker Impedance	4Ω - 16Ω
USB-A Playback	Yes
Power Supply	AC 220-240V, 50Hz/60Hz
Power Consumption	65 W
Input Sensitivity	200 mV
Digital Audio Inputs	Coaxial
Analog Audio Inputs	RCA
Analog Audio Outputs	RCA x1
Headphone Output	Yes
Ethernet Interface	Yes
Wi-Fi	Yes
Bluetooth	Yes (4.2, A2DP, SBC, AAC)
Streaming Services	Spotify, TIDAL, Deezer, Internet Radio
