3.1.8. POWER ENTRY MODULE
This is a block consisting of:
• power inlet socket;
• power outlet socket;
• fuse-holder for protecting line voltage and neutral with two 3.15A fast-blow fuses.
Situated on the side of the rear platform. The Power entry module has a maximum current rating of
7A. This determines the maximum number of machines that can be connected together. Therefore,
do not connect more than 24 Cross Forma machines with a 220 VAC mains supply, or 12 machines
with a 110 VAC mains supply.
WARNING: If other types of machines are connected together, the maximum number is
determined by their current draw.
