Technogym CROSS FORMA - Cable Specifications and Pinouts

CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 2.5
2.8. CABLES
CB-51: Brake supply cable
Brake board – Brake – Speed sensor
Brake board
CN2
Signal
Color
Brake
Speed sensor
1
Brake supply +
Brown
10
2
Brake supply -
White
5
3 RPM Yellow
Faston connected
to brown cable
4
RPM reference
Black
eyelet
CF-00: High voltage cable
Power entry module – Brake board
Power entry
module
Signal
Color
Brake board
CN4
N
Neutral
White
1
F
Line
Black
3
T
Earth
Green
5
CF-01: Cable connecting upper and lower assemblies
Brake board – Patch conn. 1
Brake board
CN1
Signal
Color
Patch conn. 1
2
Digital Gnd
White
2
3
Power Gnd
Yellow
3
4
- sensing +5 Vdc digital
Pink
4
6
+12 Vdc
Brown
6
7
+5 Vdc
Green
7
8
+sensing +5 Vdc digital
Grey
8
CF-02: Cable connecting upper and lower assemblies
Patch conn. 1 – Display board
Patch conn. 1
Signal
Color
Display Board
CN7
2
Digital Gnd
White
2
3
Power Gnd
Yellow
3
4
- sensing +5 Vdc digital
Pink
4
6
+12 Vdc
Brown
6
7
+5 Vdc
Green
7
8
+sensing +5 Vdc digital
Grey
8
