CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 2.6
CF-03: Serial communication cable between upper and lower assemblies
Brake board – Patch conn. 3
Brake board
CN3
Signal
Color
Patch conn. 3
1
NC
Brown
1
2
NC
Brown-White
2
3
Digital Gnd
Blue
3
4
Download
Blue-White
4
5
Reset
Green
5
6
Digital Gnd
Green-White
6
7
485 Tx/Rx +
Orange
7
8
485 Tx/Rx -
Orange-White
8
CF-04: Serial communication cable between upper and lower assemblies
Patch conn. 3 – Display board
Patch conn. 3
Signal
Color
Display Board
CN2
1
NC
Brown
1
2
NC
Brown-White
2
3
Digital Gnd
Blue
3
4
Download
Blue-White
4
5
Reset
Green
5
6
Digital Gnd
Green-White
6
7
485 Tx/Rx +
Orange
7
8
485 Tx/Rx -
Orange-White
8
CBQ-13: CSafe board cable
Display Board – CSafe Board
Display Board
CN1
Signal
Color
CSafe Board
CN1
1
Digital #1
Flat cable
1
…
…
…
…
14
Digital #14
Flat cable
14
CBQ-32: TGS cable
Display Board – TGS Board
Display Board
CN3
Signal
Color
TGS Board
CN1
1
+12 Vdc power supply
Yellow
1
3
Rx
White
8
5
Tx
Green
7
9
Gnd
Brown
3
