CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 2.7
REC-00: HFU receiver cable
Display board – HFU receiver
Display board
CN8
Signal
Color
HFU receiver
1
+5 Vdc power supply
Red
2
7
Pulse (beat to beat)
Blue
4
8
Gnd
Black
1
