Technogym CROSS FORMA - Disassembling the Front Platform

CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 7.24
7.16. DISASSEMBLING THE FRONT PLATFORM
Figure 7.16-1
1.
Turn the machine over on one side, resting
the frame on a box to keep the platform
raised off the ground.
2. Back off the 2 screws a using an 8-
mm hex
wrench.
Figure 7.16-2
3. Back off the two screws b
using a medium
Phillips screwdriver.
To reassemble the platform, carry out the above
steps in reverse order, paying attention to replace
the plate c as indicated in the figure to side.
