CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 6.20
6.10. THE TELEMETRIC HR SIGNAL IS INCORRECT
CORRECT USE OF BAND: Place the heart-rate band on the chest in direct contact
with the skin and make sure that it is moist in the contact area.
THE TELEMETRIC HR
SIGNAL IS INCORRECT
(Chest belt)
Are the machines correctly
spaced by the required minimum
distance?
Check the Receiver Board has
been correctly mounted on the
machine.
Reposition the machines
so they are adequately
spaced
Mount the Receiver
Board in the right way
NO
YES
NO
Check the Display SW
versione and the grounding of the
receiver.
1
2
Chest belt defective
NO
NO
YES
A
Check if it works properly using
a chest belt you are sure it's ok.
The problem persists?
3
YES
To Next Page
