Page 6.13
Follow the chart step by step in order to make a correct diagnosis. In particular, pay attention to
the checks highlighted in the numbered boxes and listed here below:
(1) Carry out the Standard Settings, as described in the relevant paragraph of the Service menu.
(2) Check that the mechanical system consisting of pedals, belt and Brake is fluid and does not
provide resistance and friction above the norm.
(3) Measure the voltage that the Brake Board provides at the winding. In the Rapid Start-up
mode, set the level of difficulty and check that the value is different from 0.
If the Brake Board is replaced, check that the correct SW version is installed or proceed
with the upgrading of the Firmware (FW), the Brake Table and the Standard Settings.
