CROSS FORMA: Service & Maintenance Manual - rev. 2.1
Page 7.2
Figure 7.1-4
7. Back off the two screws d using a 13-mm
wrench.
8. Remove the handlebar e from the machine.
9. Back off the 3 screws b, using a 6-
mm Allen
wrench, to remove the rear display support.
During reassembly, lock down the
screws d using a t
orque wrench set for
22 Nm.
To reassemble the display and the handlebar,
carry out the above steps in reverse order.
