PURESTRENGTH & BENCHES: Guida all'Assistenza Tecnica - rev. 4.1
Page 6.3
6.3. THE BUFFERS OF THE LEG PRESS EASY STARTER
LEVER ARE NOT CORRECTLY POSITIONED
CAUTION: It is important for the lever to be correctly positioned on the centre of the
easy start lever buffers, to prevent the risk of the platform lever slipping, causing injury
to the user.
Figure 6.3-1
1. Check that the platform lever (a) is resting
correctly on the centre of the buffers (b) of
the easy start lever.
Figure 6.3-2
2. To adjust the position of the easy start lever,
screwing or unscrewing the two limit stops
(c) according to need.
