PURESTRENGTH & BENCHES: Guida all'Assistenza Tecnica - rev. 4.1
Page 5.15
Figure 5.2-7
6. To reassemble the bars, carry out the
disassembly procedure in reverse order,
placing them with the wheels (c)
bars and the rollers (d) on the bottom.
After completing the assembly, check the
alignment of the bars as described in
paragraph 6.4. “The carriage sliding bars
are misaligned”.
