Teknic CLEARPATH-EC - Cable Drawings (Links to Teknic.com)

C LEAR P ATH -EC U SER M ANUAL REV 1.11 79
C ABLE D RAWINGS (L INKS T O T EKNIC . COM )
CPMS-CABLE-NET-AA039
CPMS-CABLE-NET-AA120
CPMS-CABLE-NET-AA315
CPM-CABLE-CTRL-MU120
CPMS-CABLE-PWR-KM120
CPMS-CABLE-PWR-KK660
PC-SBR-72
On tightening M12 connectors. For a reliable seal, tighten the
communication and power cables between 0.8 Nm-1.4 Nm. Tip: When
M12 cable connectors are properly tightened there should be no more
than 1-2 threads visible on the motor connectors.
