Removal and Installation Procedures
TDS5000B Series Service Manual
6--19
CDRW-drive
interconnect board
Fans
Front panel
assembly
Power supply assembly
Front
panel
board
Front panel
keypad
Floppy disk
drive
Display module
assembly
Power flex
circuit
Display adapter board
Acquisition
board
PC interface
board
Motherboard
Hard disk
drive
Front hard
disk drive
option
CDRW-drive
Figure 6--6: Internal modules
