Tektronix TDS5000B Series Service Manual

Removal and Installation Procedures
TDS5000B Series Service Manual
6--37
CDRW drive
assembly
T-15 Torxdrive
screw (1)
Tab (2)
CDRW drive
assembly
From power
supply
Disconnect from
the CDRW drive
assembly
Disconnect from
the CDRW drive
assembly
To hard
drive
Motherboard
assembly
Figure 6--19: CDRW drive assembly removal
1. Locate module to be removed: Locate the fans in the locator diagram Internal
Modules, Figure 6--6, page 6--19. Additional modules to be removed:
H Trim (all except front panel and acquisition)
Fan Removal
