Tektronix TDS5000B Series Service Manual

Calibration Procedure
5-2
TDS5000B Series Service Manual
Table 5- 1: Calibration required for module
replaced (Cont.)
Module replaced Calibration required
Micro ATX processor assem-
bly
No
Display panel or display
system
No
Power supply No
Interconnect boards No
Fans No
The sample calibration procedure requires the specific test equipment and
materials listed in Table 5--2.
Table 5- 2: Required equipment and materials
Category Specific equipment required Quantity
Signal source Wavetek 9500 Oscilloscope Calibrator, with Option 100
(high-stability time base)
1ea
Wavetek 9520 or 9530 Standard Output Module 4ea
Instrument
controller
PC-compatible computer wit h National Instruments
GPIB Controller card and National Instruments NI-488.2
for W indows software, running Windows 95 or later.
The PC must support Visual Basic win32 applications
and be able to provide a TekVisa supported GPIB
connection to the Wavetek 9500 as well as to the
TDS5000B oscilloscope
1ea
Test software Cali bration software such as the sample Visual Basic 6
program listed later in this chapter
1ea
TekVisa drivers. These are avail able on the TDS5000B
Application CD
1ea
GPIB cables GPIB cable, 1 m minimum length, Tektronix part number
002-0991-01 or similar
2ea
Required Equipment
