Tektronix TDS5000B Series Service Manual

TDS5000B Series Service Manual
6--49
Troubleshooting
WARNING. Before performing this or any other procedure in this manual, read
the General S afety Summary and Service Safety Summary found at the
beginning of this manual.
To prevent possible injury to service personnel or damage to electrical compo-
nents, please read Preventing ESD on page 6--1.
This section contains information and procedures designed to help you isolate
faults to a module.
This section assumes that service personnel have the prerequisite skills required
to work on this oscilloscope, including PC troubleshooting and Windows 2000
skills. Details of PC and Windows 2000 operation and service are not in this
manual.
For assistance, contact your local Tektronix Service Center.
Service Level
This subsection contains information and procedures designed to help you isolate
faulty modules in the oscilloscope. If a module needs to be replaced, follow the
Removal and Installation Procedures located in this section.
Check for Common Problems
Use Table 6--4 to quickly isolate possible failures. The table lists problems and
possible causes. The list is not exhaustive, but it may help you eliminate a
problem that is quick to fix, such as a blown fuse or loose cable.
Table 6--4: Failure symptoms and possible causes
Symptom Possible cause(s)
Oscilloscope will not power on
H Power cord not plugged in
H Faulty power supply
Front panel light comes on
(oscilloscope powers on), but
one or more fans will not
operate
H Faulty fan cable
H Defective fan assembly
H Faulty power supply
