Removal and Installation Procedures
TDS5000B Series Service Manual
6--31
d. Remove the floppy drive from the bracket.
Floppy drive
Floppy drive
bracket
#0 Phillips
screw (2)
Figure 6--15: Floppy disk drive removal
4. Reinstallation: Do in reverse steps a through d to reinstall the floppy disk
drive.
