Removal and Installation Procedures
6--34
TDS5000B Series Service Manual
Disconnect from
the hard drive
Hard drive
Hard drive
bracket
Screw (2)
Hard drive
From power
supply
Disconnect from
the hard drive
To
CDRW
drive
Motherboard
assembly
Figure 6--17: Desktop hard drive removal
