Removal and Installation Procedures
TDS5000B Series Service Manual
6--33
1. Locate module to be removed: Locate the Hard Disk Drive assembly in the
locator diagram Internal Modules, Figure 6--6, page 6--19. Note the location
of cables and cable connectors see Figure 6-- 16 on page 6--32. Additional
modules to be removed:
H Trim (all except front panel and acquisition)
H Right side cover
H Printer frame
CAUTION. Do not remove the hard drive when the oscilloscope is powered on.
The hard disk drive may be permanently damaged if it is removed while the
oscilloscope is powered on.
Always power off the oscilloscope before removing the hard disk drive.
2. Orient the oscilloscope: Set the oscilloscope so the bottom is down on the
work surface and the right side panel is facing you.
3. Remove the Hard Disk Drive assembly: See Figure 6--17, on page 6--34.
a. Verify that the oscilloscope is powered off.
b. Remove the 2 T-15 Torx screws that secure the Hard Disk D rive
assembly to the chassis.
c. Pull the Hard Disk Drive assembly away from the chassis far enough to
access the cables.
d. Disconnect the 2 cables from the Hard Disk Drive assembly. See Figure
6--17onpage6--34.
e. Remove the 2 T-15 Torxdrive screws that secure the hard drive bracket to
the the hard drive.
4. Reinstallation: Do in reverse steps a through e to reinstall the hard disk drive.
Hard Disk Drive
