Operating Information
TDS5000B Series Service Manual
2-3
Keyboard
GPIB
Description
Audio line in
LAN
Parallel Port
Scope VGA Output
Video (Extended
Desktop)
COM 1
Microphone in
USB (Mouse)
Timebase reference
input (EXT REF)
Trigger signal
output (AUX OUT)
CH 3 signal output
(SIGNAL OUT)
Side panel
Rear panel
Audio line out
LocationsIcon/Label
Figure 2- 1: Locations of peripheral connectors on the side panel
