Removal and Installation Procedures
TDS5000B Series Service Manual
6--9
Procedures for External Modules
The following procedures are found here and are listed in order presented.
H Line Cord
H Front Panel Knobs
H Trim (all)
H Bottom cover
H Left and Right covers
1. Orient the oscilloscope: Set the oscilloscope so the bottom is down on the
work surface and the back is facing you.
2. Remove the line cord: Pull the line cord away from the AC power connector.
1. Assemble equipment and locate modules to be removed:
2. Orient the oscilloscope: Set the oscilloscope so the bottom is down on the
work surface and the front is facing you.
3. Remove the knob(s): Grasp the knob you want to remove and pull it straight
out from the front panel
1
/
4
inch to create some clearance between the base of
the knob and the front panel. Insert the angled-tip tweezers between the knob
and front panel and use them to remove the knob. See Figure 6--1 on
page 6--10.
4. Reinstallation: To reinstall, align knob to shaft and push it in until it snaps.
CAUTION. To prevent damage to the encoders located on the circuit board, apply
pressure to the encoders while pushing the knob on the shaft.
Line cord
Front-Panel Knobs
