Tektronix TDS5000B Series Service Manual

Removal and Installation Procedures
6--8
TDS5000B Series Service Manual
Equipment Required. Most modules in the TDS5000B Digital Oscilloscope can be
removed with a screwdriver handle mounted with a size T-15, TorxR screwdriver
tip. Use this tool whenever a procedure step instructs you to remove or install a
screw unless a different size screwdriver is specified in that step. All equipment
required to remove and reinstall each module is listed in the first step of the
procedure.
Table 6--3: Tools required for module removal
Item
no.
Name Description
General tool
number
1 Screwdriver handle
Accepts TorxR-driver bits
620-440
2 T-10 Torx tip Used for removing the electrical or
optical module chassis. TorxR-driver
bit for T-10 size screw heads
640-235
3 T-15 Torx tip Used for removing most oscilloscope
screws. TorxR-driver bit for T-15 size
screw heads
640-247
4
1
/
8
inch flat-bladed screw-
driver
Screwdriver for unlocking cable
connectors
Standard tool
5 #0 Phillips screwdriver Screwdriver for removing small
Phillips screws, CD, floppy & hard
drive
Standard tool
6 Angle-Tip Tweezers Used to remove front panel knobs Standard tool
7
3
/
16
inch open-end wrench
Used to remove the rear panel nut
posts
Standard tool
8
5
/
16
inch open-end wrench
Used to remove the rear panel nut
posts
Standard tool
9 MA-800G Soldering Aid Used to remove the front panel trim Standard tool
