TESA MICRO-HITE+M User Manual

Instruction manual for MH & MH+M
126
19.10 To define an
origin
An origin can be defined when only one block is selected and then using the action. The
block can either be a single point or a circle represented by its centre.
19.11 To defined a
reference axis
A reference axis can be defined with or actions selecting:
• Two points
• Two circles
• A point and a circle
• A line
19.12 Midpoint
It is possible to construct a midpoint using action if the following two blocks are selected:
• Two points
• Two circles
• A point and a circle
19.13 Intersection of
two lines
It is possible to construct an intersection point between two lines by selecting the following
context-based action .

TESA MICRO-HITE+M Specifications

General

Brand	TESA
Model	MICRO-HITE+M
Category	Measuring Instruments
Language	English
