21.5 Transmission via
TLC (wireless)
It is also possible to send the data to a computer via the wireless TLC connection.
Therefore, it is necessary to use a TLC plug (TESA reference: 04760180) as well as the
TWIN-Station receiver box (TESA reference: 05030012)
Transmitter plug
Receiver box
The procedure for configuring such a system is not described in this document. For more
information please refer to the document about the system for wireless data transmission
or contact your local dealer.
21.6 Use of the printer
When using the printer, only the “measured” format is available. Here is an example of data
be printed:
R1
M2
11.207
mm
M3
23.069
mm
M4
23.725
mm
M5
-0.656
mm
M6
11.211
mm
M7
23.241
mm
M8
24.059
mm
M9
-0.818
mm
M10
-9.815
mm
M11
0.182
mm
M12
19.992
mm
M13
-19.811
mm
M14
108.186
mm
M15
119.179
mm
M16
21.987
mm
