Instruction manual for MH & MH+M

Your printer is now ready to be used by activating the process in the system settings. For

further information, see this chapter or the printer user manual.

6.4 Installation of the

foot switch

You can use your height gauge together with two different types of switches: operable with the

hand or the foot.

Foot switch

04768001

Hand switch

04768000

These two switches have a jack plug. To use them you must connect them to the back of your

height gauge, above the power connector.

Default Chapter2
