6. Press or again in order to start a new measurement process, press to go
back to ST1 mode (respectively ST2) or to go back to the main page.
1. Once the measurement mode is activated, position the probe above the surface to be
measured.
2. Move the probe, so that it establishes contact with the surface of the workpiece to be
measured. At that moment, you can decide to use the locking ring (for further details,
see this chapter). It allows you to get the probe positioned at a predefined height in order
to carry out your measurement (also using the fine adjustment system). Make sure that
the colour of the strain gauge (on the right side of the screen) will stay green.
3. Move the workpiece to be measured back and forth, so that the probe is displaced along
the whole measurement zone.
