TESA MICRO-HITE+M User Manual

Instruction manual for MH & MH+M
90
One probe hit
One probe hit
The point is measured.
You can change from one probe hit to two (and vice versa) by pressing the key on the main
result bar.
14.5 Secondary
results
When measuring an element by double probing, several results are displayed on the screen.
In addition to the main value, 3 secondary values can also be available (in green below).
The main value is automatically saved in the measurements list, which is not the case for
the secondary results.
In the screenshot above, the secondary values are:
Icon
Description
Value
Probing up
107.223
Midpoint between the two
measurements
97.247
Probing down
87.270
In certain cases, a secondary result could also be a wanted one. Click on the key , which
allows you to save the value in the measurements list.
