Instruction manual for MH & MH+M
49
Managing the air cushion
Managing the keyboard’s backlight
9.3 Measurement
parameters
Definition of options
Definition of the resolution
Metric: 0.00, 0.000, 0.0000
Imperial: .000, .0000, .00000
Managing the unit
Metric
Imperial
Definition of the angle unit
DD:MM:SS
Degree
Radian
Managing the temperature unit
Celsius
Fahrenheit
Size of the master piece
Height of the automatic positioning of the probe when starting the probe
calibration’s process (for MH+M)
Retract distance after probe hit (for MH+M)
Speed (for MH+M)
Fast displacement speed (for MH+M): 30, 50, 70, 90 mm/s
Probing speed (for MH+M): 7, 14 mm/s
The technical specifications announced for a MICRO-
HITE+M were calculated with a probing speed of 7mm/s.
Any variation in the probing speed in comparison with the
latter may also lead to variations in the precision of the
instrument.
Waiting time when running a program (for MH+M):
before moving to another measurement zone
before the measurement
If the distance between the current and the next measurement area is
close enough, the software will activate the countdown until the next
measurement only once.
