TESA MICRO-HITE+M User Manual

Instruction manual for MH & MH+M
46
The measurement blocks are defined by:
No.
Description
1
Number of the measurement block
2
Editable name of the measurement
block
3
Measurement result
4
Reference linked to the measurement
result
5
Feature of the measured element
6
Measurement action or measured
element
Our example above shows that the third measurement of the sequence has been carried out in
datum A on a groove with a dimension of 39.63 mm.
The maximum number of measurement blocks (considering all different
measurement lists as ST1, ST2,…) is approximately 2000. Since each block
does not have the same amount of information, it is possible that this
upper limit varies depending on the measurements stored in the histories.
An alert message is displayed when the maximum limit is reached.
8.6 Location
