TESA MICRO-HITE+M User Manual

Instruction manual for MH & MH+M
37
24. Screw the control panel on the articulated support.
Any cable connections have to be established while the instrument is turned
off. Make sure that the instrument is turned off each time the control
panel/height gauge cable is connected or disconnected.
25. Connect the control panel to the height gauge
26. Make sure that the battery is well fixed in the height gauge.
27. Connect the height gauge to a source of power using the power supply unit for direct
mains operation or subsequent use (with batteries once they are charged).

TESA MICRO-HITE+M Specifications

General

Brand	TESA
Model	MICRO-HITE+M
Category	Measuring Instruments
Language	English
