19
Feature Values
Battery charge time <6hr
Battery operation
time
2.5hr (with gas cooler and IR module) /
4.5hr (without gas cooler and IR module)
Dimensions 12.99 x 5.03 x 17.24 in.
Housing ABS URL 94V0
Weight 10.58 lbs. (completely assembled)
Memory 250000 readings
Flue gas
overpressure
20.07 "H
2
O
Underpressure max. 120.43 "H
2
O
Pump volumetric
flow rate
1 l/min (controlled), standard litre ±0.1l/min
Hose length
max. 53 ft. (corresponds to five probe hose
extensions)
Diluting gas Fresh air or nitrogen
Flue gas dust load max. 20g/m³
Humidity load max. 158 °F td at measuring input
USB interface USB 2.0
Trigger input Voltage: 5...12V (falling or rising flank)
Pulse width: >1 s
Load: 5V/max. 5mA, 12V/max. 40mA
Bluetooth option Class1 module (reach <100m in open field)
