28
4.2.4. Functions/instrument options
Some functions are available as optional extras. The functions your
analyzer box is equipped with (condition as delivered) is shown on
the identification plate on the bottom side of the analyzer box.
Imprint Description
CO, NO, NO
2
, SO
2
,
NO
low
, CO
low
,
CxHy/HC, H
2
S, O
2
,
CO
2
-(IR)
The sensor of the specified type is check
marked
SG
Special main gas pump for long-term
measurement
1/x
Measurement range extension (individual
dilution with selectable dilution factors)
DC DC-voltage input (11…40V DC)
∆p-0
Automatic pressure zeroing for flow
measurement
GP
Gas preparation thermoelectric chiller for
higher measuring accuracy
Fresh air valve for overall dilution (x5) to
measure high concentrations.
Contains Bluetooth
FCC ID:QOQWT11
IC ID:4620-A
Bluetooth module
4.2.5. Menu guidance analyzer box
Main menu Menu Description
Applications
-
Select an application in
accordance with the
measuring task to be
performed
Folders
-
Create and manage folders
and measurement sites
Fuels & Test option
- Select and configure fuels
Saved measurements
-
Display and manage
measurements
