TESTO 350 - Display

22
4.1.3. Display
1 Status bar (dark grey background):
• Display of date and time (valid for control unit and analyzer
box).
• Display of Bluetooth
status, power supply and remaining
rech. batt. capacity (valid for control unit):
Icon Feature
- Blue background/white symbol = Bluetooth
on,
Bluetooth connection to measuring box set up
- Grey background/white symbol = Bluetooth
off
- Blue background/green symbol = Bluetooth
connection to analyzer box up and running
Battery operation
Indication of remaining capacity of the rech. batt.
by color and filling degree of the battery symbol
(green = 20-100%, red = < 20%)
Power supply operation
Indication of remaining capacity of rech. batt: see
above
