58
Possibly:
> Enter the currently valid password:
[Enter] → Enter password → [Next] → [OK].
Changing the password:
1. [Edit].
2. Enter the new password → [Next].
3. [Edit].
4. Enter the new password again to confirm → [Next].
5. Save changes: [Finished].
6.1.2.12. Analog input
(Only available via Analyzer Box tab)
Power cable 0554 0007 (accessory) is required.
An analog signal is read in by an external instrument. The signal is
scaled and assigned to a physical parameter. The calculated value
is displayed.
Before the analyzer is started, insert power cable 0554
0007 at the measuring box probe input port.
1. Select analog signal (±1 V, ±10 V, 0…20 mA) at power cable
0554 0007.
Activating the function:
> [
] → Device settings → [OK] → Analog input → [OK].
Configuring the analog input:
1. Measurement vs → [Change].
2. Enter or set values: [▲], [▼], [◄], [►] → [OK].
3. Save the entry: [Finished].
4. Entry of min. and max. measure value limit (Min0V or Min0mA)
→ [Change].
5. Enter or set values: [▲], [▼], [◄], [►] → [OK].
6. [Finished].
6.1.2.13. Data bus
Bus address
See Connection using a data bus cable, page 35.
