51
It is possible to calibrate/adjust with test gas when dilution is
switched on to eliminate any measuring errors caused by dilution
(see Calibration/adjustment page 61).
Calling up the function:
> [
] → Device settings → [OK] → Dilution → [OK]
1. Select to dilute all (x5): [
] → [Change].
2. Select setting: [On] / [Off].
3. Confirm the entry: [OK].
6.1.2.2. Measurement view
(only available via Analyzer Box tab)
The parameters/units and the display representation (number of
readings displayed per display page) can be set.
The settings are only valid for the currently chosen combination of
application and measurement type, which is indicated by the
symbol (application) and the text (measurement type) in the info
field.
Total overview of selectable parameters and units (available
selection depends on the chosen application / measurement type):
Display Measurement parameter
Tstack
Flue gas temperature
Tamb
Combustion air temperature
∆p
Differential pressure
∆p1
Differential pressure 1 (flue gas + m/s)
∆p2
Differential pressure 2 (flue gas + ∆P)
Draft
Flue draft
Pabs
Absolute pressure
Pump
Pumping capacity
O2
Oxygen
O2ref
Oxygen reference
CO2
Carbon dioxide
CO2max
maximal carbon dioxide content
qAnet
Abgasverlust
CO
Carbon monoxide
COundil
Carbon monoxide undiluted
