91
7.11.4. Replacing the motor of the condensate pump
The condensate pump is only available in instruments with
the gas preparation (GP) option.
1. Unlock and remove the cover.
2. Unlock the two lateral clip locks of the condensate pump and
pull off the pump head.
3.Pull the inlet and outlet hoses off the sockets on the analyzer
box.
