TESTO 350 - Status Display

26
1 Condensate trap and condensate container,
2 Locking/unlocking button for control unit
3 Particle filter
4 Filter fresh air inlet (option: fresh air valve/measurement range
extension overall (5x))
5 Contact bar for connection to control unit
6 Guide pins for locking with control unit
7 Diluting gas filter
8 Status display
9 Full-view slider for marking/identification
10 Gas outlet 1
11 Fresh air inlet
12Gas outlet 2
4.2.2. Status display
The status display shows the operating status of the analyzer box:
Display Status
green/permanent (analyzer box
switched on)
Power supply operation or
rech. batt operation/rech.
batt. fully charged
red/flashing (analyzer box switched
on)
• Rech. batt.
operation/residual rech.
batt. capacity < 20%
• other device error
green/flashing (analyzer box switched
off)
Charge rech. batt.
green/permanent (analyzer box
switched off)
Rech. batt. fully charged,
trickle charge
green, red/alternately flashing Flash mode active
