73
Flow measurement: Before the measurement beings, make
the measurement site settings (Pitot tube factor and
correction factor), see Folders / Measurement sites, page
43.
Do not measure for longer than 5 min., as the drift of the
pressure sensor could have the effect that the readings are
outside the tolerance limits.
Activating the function:
✓ Application selected.
> Choose the measurement type: [
], [ ] → [OK].
Options
> [Options] → Save: The readings are saved in a record.
> [Options] → Print: The readings from a record are printed.
> [Options] → Fuels & Test option: Select fuel.
> [Options] → Dilution: Select the dilution factor.
> [Options] → Measurement view: (This function is not available
during a measurement): The configure measurement view
menu is opened.
> [Options] → Folders: (This function is not available during a
measurement): - The folder Folders/Measurement sites is
opened.
> [Options] → Programs: The programs menu is opened.
> [Options] → Recalibrate: (This function is not available during
a measurement): The gas sensors are zeroed.
> [Options] → Number of lines: Change the number of
measuring values per display page.
> [Options] → Show Graphic: The readings are displayed in
form of a line graph.
> [Options] → Configure Graphic: The measurement
parameters to be represented (max. 4) can be displayed (
) or
hidden ( ).
- Possibly: Gas zeroing (30s).
> Depressurize the pressure sensor and perform pressure
zeroing.
Performing the measurement:
1. Start measurement: [
].
