Thermo King SR-2 SmartReefer2 User Manual

Section 2 – SR-2 Hardware Description
J12 - iBOX Connector – arranged by pin number
Pin
Number
Wire
Number
Description
1 CANL-BLK1 To iBOX Option
2 CANH-RED1 To iBOX Option
3 DRAIN-WHT To iBOX Option
4 ON_OFF-RED2 To iBOX Option
5 2P-BLK2 To iBOX Option
6 8XP-BLK3 To iBOX Option
7 None Not Used
8 CH-RED3 Chassis ground to iBOX Option
J13 – Remote Controller Connector – arranged by pin number
Pin
Number
Wire
Number
Description
1 CANL-BLK1-08 To Remote Controller Panel
2 CANH-RED1-07 To Remote Controller Panel
3 DRAIN-WHT-02 To Remote Controller Panel
4 ON_OFF-RED2-03 To Remote Controller Panel
5 2P-BLK2-05 To Remote Controller Panel
6 8XP-BLK3-04 To Remote Controller Panel
7 None Not Used
8 CH-RED3-03 Chassis ground to Remote Controller Panel
Screw Terminal Power Connections
Terminal
Number
Wire
Number
Description
2 RED-03 From fusible link (battery power)
2A 2A-01 From alternator
H H-01 To air intake heater or glow plugs
CH CHP Chassis ground
2-19
31 January 2005
