Section 3 – SR-2 Software Description
Electric to Diesel Auto Switch Enabled?
Micro Rev
All
HMI Rev
All
Choices
YES or NO
Factory Set
NO
Exceptions
Description This feature allows the Auto Switch
from Electric to Diesel to be enabled or disabled. If
this feature is set YES, the unit will switch
automatically to diesel mode when standby power is
disconnected or fails. If the feature is set NO, the
operator must physically switch the unit to diesel
mode.
SL Unit?
Micro Rev
All
HMI Rev
All
Choices
YES or NO
Factory Set
To match unit as built
Exceptions
Description SL units should be set YES. All
other units should be set NO.
High Capacity Unit?
Micro Rev
All
HMI Rev
All
Choices
YES or NO
Factory Set
To match unit as built
Exceptions
Description If the unit was built as a high
capacity unit (2600 RPM high speed), this setting
should be set to YES to allow the engine to run at
higher rpm in high speed. If the unit was not built as
a high capacity unit this setting must be set to NO.
High Capacity Fresh Is?
Micro Rev
All
HMI Rev
All
Choices
YES or NO
Factory Set
NO
Exceptions Available only if the high capacity
option is selected.
Description If the unit was built as a high
capacity unit, this setting should be set to YES to
allow the engine to run at higher rpm (1730 rpm) in
low speed. If the unit was not built as a high
capacity unit this setting must be set to NO.
Defrost Motor Equipped?
Micro Rev
All
HMI Rev
All
Choices
YES or NO
Factory Set
To match unit as built
Exceptions
Description This feature specifies if the unit is
equipped with a defrost solenoid or defrost motor. If
the unit is equipped with a defrost motor this feature
should be set Yes. If the unit is not equipped with a
defrost motor this feature should be set No.
NOTE: All SL-400e units are equipped with defrost
motors and this feature must be set YES.
NOTE: A different interface board is required for
units equipped with a damper gear motor. The
damper gear motor interface board has added
electronic circuitry to drive the gear motor.
Fuel Sensor Type
Micro Rev
All
HMI Rev
All
Choices
NONE, SOLID STATE or FLOAT
Factory Set
NONE
Exceptions
Description This feature is used to select the
type of fuel level sensor installed, either float type or
solid state type. If no fuel level sensor is installed,
this feature should be set to NONE.
3-45
31 January 2005
