Section 3 – SR-2 Software Description
Out of Range Checking (for current sensor)
Micro Rev
All
HMI Rev
All
Choices
ON or OFF
Factory Set
ON
Exceptions
Description This feature allows the Out of
Range Checking feature to be turned on or off. If
Out of Range Checking is turned on, an alarm will
be set if the temperature, as sensed by the specified
sensor, is above or below setpoint by more than the
number of degrees determined by the setting of
LOW and HIGH programmable features. The out of
range condition must exist for 1 hour before the
alarm is set. A visual notification will be provided to
the driver on the standard display, as shown below.
MENU
35
°F
35
OUT OF RANGE LIMIT
SET SENSORSGAUGES
POINT
.8
Low
Micro Rev
All
HMI Rev
All
Choices
From -1.0° to –20.0° in 0.1-degree
increments, in either Fahrenheit or
Celsius.
Factory Set
–10.8°F (-6.0°C)
Exceptions
Description This feature allows the low limit for
Out of Range Checking to be set.
High
Micro Rev
All
HMI Rev
All
Choices
From 1.0° to 20.0° in 0.1-degree
increments, in either Fahrenheit or
Celsius.
Factory Set
10.8°F (6.0°C)
Exceptions
Description This feature allows the high limit
for Out of Range Checking to be set.
Italian Option
Micro Rev
All
HMI Rev
All
Choices
ON or OFF
Factory Set
OFF
Exceptions
Description If this feature is turned ON, the
driver is presented a visual “Out of Range Limit”
notification and flashes the backlight if the box
temperature rises above -15°C. The visual
notification appears on the Standard Display as
shown below.
MENU
35
°F
35
OUT OF RANGE LIMIT
SET SENSORSGAUGES
POINT
.8
3-42
31 January 2005
