Section 4 – SR-2 Operation
Adjust Brightness
The brightness of the HMI Control Panel display can be adjusted to allow for changing ambient light conditions.
The choices available to the operator are HIGH, MEDIUM, LOW and OFF. OFF actually results in a very dim
screen suitable for low light conditions.
Display brightness is adjusted using the Adjust Brightness Menu. From the Standard Display, press the MENU
key.
OFF
ON
-MENU
SETPOINTTEMPERATURE
35.
8
°F
35
CYCLE SENTRY
+
The Language Menu or Alarm Menu will appear. Press the NEXT key as required to show the Adjust Brightness
Menu. When the Adjust Brightness Menu is shown press the SELECT key.
OFF
ON
EXIT NEXT
MAIN MENU
ADJUST BRIGHTNESS
SELECT BACK
4-53
31 January 2005
